Module Analog Mitsubishi Q62AD-DGH (2 ngõ vào)

Name: Module Analog Mitsubishi Q62AD-DGH (2 ngõ vào) - admin
SKU: Q62AD-DGH

SKU: Q62AD-DGH
Nhà Sản Xuất: Mitsubishi
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: hóa đơn VAT

Dịch vụ kèm theo:
✓ Lập trình & Sửa chữa PLC Mitsubishi theo yêu cầu
✓ Lắp đặt & vận hành tận nơi
✓ Hỗ trợ kỹ thuật trọn đời

Mô tả

FA-MOD PLC: Analogue I/O Module

Tên sản phẩm	Q62AD-DGH
Series	MELSEC-Q SERIES
Type	ANALOG INPUT
Power Supply (V)	24
Current Type	DC
Occupied I/O Points on PLC	16
Integrated Analogue Inputs	2
Input Current Range (mA)	4-20
Wiring	SCREW
Int. Current Consumption (A)	0,22
Width (mm)	27,4
Height (mm)	98
Depth (mm)	112
Weight (kg)	0,19

Module Analog Mitsubishi Q series

Model	Mô tả
Analog Input
Q64ADH	4 channels, input: -10…10 V DC, 0…20 mA DC, output (resolution): 0…20000, -20000…20000, -5000…22500, conversion speed: 20 μs/channel, 18-point terminal block
Q64AD	4 channels, input: -10…10 V DC, 0…20 mA DC, output (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, 0…16000, -16000…16000, conversion speed: 80 μs/channel, 18-point terminal block
Q64AD-GH	4 channels, input: -10…10 V DC, 0…20 mA DC, output (resolution): 0…32000, -32000…32000, 0…64000, -64000…64000, conversion speed: 10 ms/4 channels, 18-point terminal block, channel isolated
Q68AD-G	8 channels, input: -10…10 V DC, 0…20 mA DC, output (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, 0…16000, -16000…16000, conversion speed: 10 ms/channel, 40-pin connector, channel isolated
Q68ADV	8 channels, input: -10…10 V DC, output (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, 0…16000, -16000…16000, conversion speed: 80 µs/channel, 18-point terminal block
Q68ADI	8 channels, input: 0…20 mA DC, output (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, conversion speed: 80 μs/channel, 18-point terminal block
Q62AD-DGH	2 channels, input: 4…20 mA DC, output (resolution): 0…32000, 0…64000, conversion speed: 10 ms/2 channels, 18-point terminal block, channel isolated, power supply to 2-wire transmitter
Q66AD-DG	6 channels, input: 0…20 mA, 4…20 mA, output (resolution): 0…4000, 0…12000, conversion speed: 10 ms/channel, 40-pin connector, channel isolated, power supply to 2-wire transmitter
Analog Output
Q62DAN	2 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, -16000…16000, output: -10…10 V DC, 0…20 mA DC, conversion speed: 80 μs/channel, 18-point terminal block
Q62DA	2 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, -16000…16000, output: -10…10 V DC, 0…20 mA DC, conversion speed: 80 μs/channel, 18-point terminal block
Q64DAH	4 channels, input (resolution): 0…2000, -2000…20000, output: -10…10 V DC, 0…20 mA DC, conversion speed: 20 μs/channel, 18-point terminal block
Q64DAN	4 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, -16000…16000, output: -10…10 V DC, 0…20 mA DC, conversion speed: 80 μs/channel, 18-point terminal block
Q64DA	4 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, -16000…16000, output: -10…10 V DC, 0…20 mA DC, conversion speed: 80 μs/channel, 18-point terminal block
Q62DA-FG	2 channels, input (resolution): 0…12000, -12000…12000, -16000…16000: output, -10…10 V DC, 0…20 mA DC, conversion speed: 10 ms/2 channels, 18-point terminal block, channel isolated
Q66DA-G	6 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, -16000…16000, output: 0…5 V DC, -10…10 V DC, 0…20 mA DC, 4…20 mA DC, conversion speed: 6 ms/channel, 40-pin connector, channel isolated
Q68DAVN	8 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, -16000…16000, output: -10…10 V DC, conversion speed: 80 μs/channel, 18-point terminal block
Q68DAV	8 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, -16000…16000, output: -10…10 V DC, conversion speed: 80 μs/channel, 18-point terminal block
Q68DAIN	8 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, output: 0…20 mA DC, conversion speed: 80 μs/channel, 18-point terminal block
Q68DAI	8 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -12000…12000, output: 0…20 mA DC, conversion speed: 80 μs/channel, 18-point terminal block
Analog I/O
Q64AD2DA	Analog input: 4 channels, input: -10…10 V DC, 0…20 mA DC, output (resolution): 0…4000, -4000…4000, 0…12000, 0…16000, -16000…16000, conversion speed: 500 μs/channel, analog output: 2 channels, input (resolution): 0…4000, -4000…4000, 0…12000, -16000…16000, output: -10…10 V DC, 0…20 mA DC, conversion speed: 500 μs/channel, 18-point terminal block, logging function
Load cell input
Q61LD	1 channel, input: load cell output 0.0…3.3 mV/V, 18-point terminal block
CT input
Q68CT	8 channels, input: CT 0…5 A AC, 0…50 A AC, 0…100 A AC, 0…200 A AC, 0…400 A AC, 0…600 A AC, 18-point terminal block
Loop control
Q62HLC	2 channels, input: thermocouple/micro voltage/voltage/current, output: 4…20 mA, 18-point terminal block, channel isolated, 5 PID control modes
