Module nhiệt độ Mitsubishi Q64TDV-GH (4 ngõ vào, loại K)

Name: Module nhiệt độ Mitsubishi Q64TDV-GH (4 ngõ vào, loại K) - admin
SKU: Q64TDV-GH

SKU: Q64TDV-GH
Nhà Sản Xuất: Mitsubishi
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: hóa đơn VAT

Dịch vụ kèm theo:
✓ Lập trình & Sửa chữa PLC Mitsubishi theo yêu cầu
✓ Lắp đặt & vận hành tận nơi
✓ Hỗ trợ kỹ thuật trọn đời

Mô tả

FA-MOD PLC: Temperature Module

Tên sản phẩm	Q64TDV-GH
Series	MELSEC-Q SERIES
Type	TEMPERATURE INPUT
Occupied I/O Points on PLC	16
Integrated Analogue Inputs	4
Input Type	THERMOCOUPLE
Applicable Thermocouple Type	T, S, R, N, K, J, E, B
Int. Current Consumption (A)	0,5
Width (mm)	27,4
Height (mm)	98
Depth (mm)	90
Weight (kg)	0,25

Module nhiệt độ Mitsubishi Q Series

Model	Mô tả
Q64TD	4 channels, thermocouple (B, R, S, K, E, J, T, N), conversion speed: 40 ms/channel, 18-point terminal block, channel isolated
Q64TDV-GH	4 channels, thermocouple (B, R, S, K, E, J, T, N), micro voltage (-100…100 mV), conversion speed: (sampling cycle x 3)/channel, 18-point terminal block, channel isolated
Q68TD-G-H01	8 channels, thermocouple (B, R, S, K, E, J, T, N), conversion speed: 320 ms/8 channels, 40-pin connector, channel isolated, disconnection monitoring
Q68TD-G-H02	8 channels, thermocouple (B, R, S, K, E, J, T, N), conversion speed: 640 ms/8 channels, 40-pin connector, channel isolated, disconnection detection
Q64RD	4 channels, platinum resistance thermometer (Pt100, JPt100), conversion speed: 40 ms/channel, 18-point terminal block
Q64RD-G	4 channels, RTD (Pt100, JPt100, Ni100), conversion speed, 40 ms/channel, 18-point terminal block, channel isolated
Q68RD3-G	8 channels, RTD (Pt100, JPt100, Ni100), conversion speed: 320 ms/8 channels, 40-pin connector, channel isolated
Q64TCTTN	4 channels, thermocouple (K, J, T, B, S, E, R, N, U, L, PLII, W5Re/W26Re), no heater disconnection detection, sampling cycle: 500 ms/4 channels, 18-point terminal block, channel isolated, heating-cooling control
Q64TCTT	4 channels, thermocouple (K, J, T, B, S, E, R, N, U, L, PLII, W5Re/W26Re), no heater disconnection detection, sampling cycle: 0.5 s/4 channels, 18-point terminal block, channel isolated
Q64TCTTBWN	4 channels, thermocouple (K, J, T, B, S, E, R, N, U, L, PLII, W5Re/W26Re), heater disconnection detection, sampling cycle: 500 ms/4 channels, 18-point terminal block x 2, channel isolated, heating-cooling control
Q64TCTTBW	4 channels, thermocouple (K, J, T, B, S, E, R, N, U, L, PLII, W5Re/W26Re), heater disconnection detection, sampling cycle: 0.5 s/4 channels, 18-point terminal block x 2, channel isolated
Q64TCRTN	4 channels, platinum RTD (Pt100, JPt100), no heater disconnection detection, sampling cycle: 500 ms/4 channels, 18-point terminal block, channel isolated, heating-cooling control
Q64TCRT	4 channels, platinum RTD (Pt100, JPt100), no heater disconnection detection, sampling cycle: 0.5 s/4 channels, 18-point terminal block, channel isolated
Q64TCRTBWN	4 channels, platinum RTD (Pt100, JPt100), heater disconnection detection, sampling cycle: 500 ms/4 channels, 18-point terminal block x 2, channel isolated, heating-cooling control
Q64TCRTBW	4 channels, platinum RTD (Pt100, JPt100), heater disconnection detection, sampling cycle: 0.5 s/4 channels, 18-point terminal block x 2, channel isolated
